Solar Photovoltaic Manufacturing 1.2mm Metal Roll Former 20m/Min

Product Categories
Liming Stamping Form Machine Co.,Ltd
Contact Now

Solar Photovoltaic Manufacturing 1.2mm Metal Roll Former 20m/Min

Brand Name : LIMING

Model Number : LM-Solar 5.7

Certification : CE、BV、ISO

Place of Origin : China

MOQ : 1

Price : Negotiation

Payment Terms : T/T, L/C, D/A, D/P

Supply Ability : 450set/Year

Delivery Time : 45 work days

Packaging Details : Nude、Anti-dust film, Anti-rust cloth

Production Capacity : 15-20m/min

Rollers’ material : Steel #45

Weight : 5T

Rolling thinckness : 1.2-2.5mm

Cutting blade material : Cr12 Frequency Quenching

Power supply : 380V 50Hz 3ph

Contact Now

Easy to install Automatic roll forming line for solar structure

In the photovoltaic power generation technology, in order to meet the installation requirements of large-size battery modules, and can be used in areas with high wind speeds, a solar mounting system is designed. The solar mounting system does not need to be welded on site. It can be completely installed in the bolt holes. We can provide a full-automatic roll forming line for the solar structure of the solar stent

Machinable Material : A) Hot-rolled and cold rolled steel Thickness(MM): 1-2.5
B) Hot-dip galvanized sheet
C) Pre-Galvanized Steel
D) Mill(Plain/Black) Steel
E) Aluminum
F) Stainless Steel
Yield strength : 250 – 350 Mpa
Tensil stress : G250 Mpa-G350 Mpa
Decoiler : Manual decoiler * Hydraulic decoiler (Optional)
Punching system : Hydraulic punching station * Punching press (Optional)
Forming station : 28 * According to your profile drawings
Main machine motor brand : Siemens * Siemens (Optional)
Driving system : Gearbox drive
Machine structure: Forged Iron station
Forming speed : 15-20 (M/MIN) * Or according to your profile drawings
Rollers’ material : Steel #45 * GCr 15 (Optional)
Cutting system : Flying hydraulic cut * Flying saw cut (Optional)
Frequency changer brand : Yaskawa * Siemens (Optional)
PLC brand : Siemens
Power supply : 380V 50Hz 3ph * Or according to your requirment
Machine color : Crimson * Or according to your requirment

Solar Photovoltaic Manufacturing 1.2mm Metal Roll Former 20m/MinSolar Photovoltaic Manufacturing 1.2mm Metal Roll Former 20m/MinSolar Photovoltaic Manufacturing 1.2mm Metal Roll Former 20m/MinSolar Photovoltaic Manufacturing 1.2mm Metal Roll Former 20m/Min
